| Model | MP-C／ULS-B |
|---|---|
| Output | 4~20 mA、RS485 |
| Power supply | 18～28 VDC |
| Application | used in municipal, chemical, storage and transportation and other industrial environments for liquid level measurement of rivers, pools, tanks and so on |
| Description | Ultrasonic liquid level meter is a high-performance, high-reliability non-contact liquid/level measurement instrument, designed for the height measurement of various liquids and solid materials. |
Ultrasonic liquid level meter is a high-performance, high-reliability non-contact liquid/level measurement instrument, designed for the height measurement of various liquids and solid materials. With its cost-effective, easy to install and maintain features, it is widely used in municipal, chemical, storage and transportation and other industrial environments for liquid level measurement of rivers, pools, tanks and so on. The product supports optional NB-IoT wireless communication function, users can realize data viewing and remote monitoring through the “Instrument Cloud” platform, which greatly improves the convenience and intelligent level of measurement.
Ultrasonic liquid level meter utilizes the principle that ultrasonic waves reflect when encountering the interface of liquid medium (solid medium) with different densities, and calculates the liquid level/distance by accurately determining the transmission time of ultrasonic waves. Users need to set the installation height and measurement mode in the menu, and the liquid level value can be derived from the formula “installation height - distance value”.
| Measuring range: | (0~5)m / (0~10)m / (0~15)m |
| Blind zone: | ≤0.4m (5m, 10m range) ≤0.6m (15m range) |
| Accuracy: | ±0.3%FS / ±0.5%FS |
| Resolution: | 1mm or 0.1%FS (whichever is greater) |
| Protection level: | instrument IP65, probe IP68 |
| Output: | (4～20)mA variable output, RS485 communication output (optional), NB-IoT wireless communication (optional) |
| Power supply: | (18～28)VDC |
| Power consumption: | according to the different output configurations, power consumption between 0.48W and 1.1W |
| Operating temperature: | instrument (-20 ~ 60)℃, probe (-20 ~ 80)℃ |
| Measuring range: | (0～5)m / (0～10)m / (0～15)m |
| Blind zone: | ≤0.3m (5m range) ≤0.35m (10m range) ≤0.5m (15m range) |
| Accuracy: | ±0.3%FS / ±0.5%FS |
| Resolution: | 1mm or 0.1%FS (whichever is greater) |
| Protection level: | IP65 for the main unit, IP68 for the probe |
| Output: | Isolated (4～20)mA variable output, isolated RS485 communication output, 2-channel SPST alarm output (standard), optional 4-channel SPST |
| Power supply: | (100 ~ 240) VAC, 50/60Hz or (18 ~ 28) VDC |
| Power Consumption: | 1W to 2.1W depending on power supply voltage and output configuration. |
| Operating temperature: | Main unit (-20～60)℃, probe (-20～80)℃. |
Rich menu interaction: Provide Chinese/English menu, the operation is simple and clear, convenient for users to get started quickly.
Wireless communication function: optional NB-IoT wireless communication module, support cell phone APP real-time view data, realize remote monitoring.
High-quality human-computer interaction: Split-type adopts touch button design, which improves the user's operation experience.
Failure self-diagnostic technology: built-in failure self-diagnostic function, real-time detection and prompting fault information, convenient for user self-check and maintenance.
Multiple working condition algorithms: Provide a variety of working condition algorithms to adapt to the measurement needs of different environments and improve the accuracy of measurement.
High measurement resolution: the resolution is less than 3mm, ensuring the accuracy of measurement results.
Fast response: the fastest response time of 2 seconds, to meet the real-time requirements of the high demand for measurement scenarios.
Automatic Temperature Compensation: Compensate the speed of sound according to the temperature to ensure the stability of the measurement results.
Echo curve display: it can display the echo curve and monitor the echo energy intensity in real time, which is convenient for on-site debugging and troubleshooting.
Ultrasonic level meter is widely used in municipal, chemical, storage and transportation and other industrial fields, applicable to rivers, pools, tanks, tankers and other liquid level measurement scenarios. Its non-contact measurement avoids the pollution and wear problems caused by the contact measurement of traditional liquid level meters, and improves the reliability and accuracy of measurement.
Ordering Information
For more information about ultrasonic level meters or to place an order, please contact our sales team. We will provide you with professional technical support and excellent after-sales service to ensure that your measurement needs are met.
The above product details page is for reference only, please refer to the actual product for specific product information and parameters.
